Since 1998, Sahil Graphics has been a well-known manufacturer of the best paper cup making machine in India. We have been constantly growing our production capabilities to uncover a variety of sectors. Our constant dedication to quality and innovation has established a global standard.
We are a trusted partner for organizations throughout the world trying to simplify their production operations. This is primarily due to our reputation for providing high-quality equipment and a customer-centric mindset. Our extensive product line, which was created to meet the many needs of contemporary enterprises, is proof of our commitment to excellence.
About 250 productive machines are in operation worldwide for Sahil Graphics, and they are renowned for their high caliber and durability. You can always rely on us to deliver state-of-the-art solutions that will boost your workplace output.
Selecting Sahil Graphics means selecting a partner who is dedicated to your success. Sahil Graphics is a notable option when it comes to choosing the best paper cup making machine.
Serving more than 2000 clients both locally and internationally makes us proud, and we always put their needs first. Our machines are highly dependable and reasonably priced, which makes them perfect for contemporary businesses looking for cost-effective solutions.
The XT 1300, our top model, is designed to revolutionize your manufacturing process. This sophisticated equipment, with its remarkable 130 cups per minute capacity, is perfect for companies looking to increase production without compromising quality.
For both small and large businesses, the XT 1300 provides flexible options that are customized to meet your needs. Because of its advanced features, which guarantee efficacy, precision, and accuracy, it’s a wise investment for companies looking to increase their production capacity.
| S no | Model | |||
|---|---|---|---|---|
| 1 | Automation | Open CAM, Gear based, Fully Automatic Machine with 10 Moulds | ||
| 2 | Lubrication | Auto Lubrication | ||
| 3 | Maximum Speed | 120-130 Pcs/Min | ||
| 4 | Stable Speed | 100-110 Pcs/Min | ||
| 5 | Power source | 3 Phase 380V 50Hz | ||
| 6 | General power | 5.5 kw | ||
| 7 | Weight | 2300 Kg | ||
| 8 | Dimension | 2500x1500x1800 MM | ||
| 9 | Cup Size | 40 ML - 450ML | ||
| 10 | Maximum Height | 130 MM | ||
| 11 | Paper Specification | 160-300 GSM(Single/Double PE Coated) |
Sahil Graphics’ XT 1200 is a remarkable device that can produce an astounding 120 cups per minute. Its environmentally friendly design, which maximizes performance and reduces waste, is what makes it unique. For companies looking to enhance their production procedures while simultaneously lessening their environmental effect, this makes it a wise decision.
The cutting-edge technology of the XT 1200, which guarantees peak performance and efficiency, is one of its primary characteristics. Its easy-to-use interface also saves operators time and effort by making management and maintenance simple.
| S no | Model | |||
|---|---|---|---|---|
| 1 | Automation | Open CAM, Gear based, Fully Automatic Machine | ||
| 2 | Lubrication | Auto Lubrication | ||
| 3 | Maximum Speed | 120 Pcs/Min | ||
| 4 | Stable Speed | 95-100 Pcs/Min | ||
| 5 | Power source | 3 Phase 380V 50Hz | ||
| 6 | General power | 4 kw | ||
| 7 | Weight | 1300 Kg | ||
| 8 | Dimension | 2100x1100x1700 MM | ||
| 9 | Cup Size | 50 ML - 270 ML | ||
| 10 | Maximum Height | 90 MM | ||
| 11 | Paper Specification | 150-350 GSM(Single/Double PE Coated) |
Our DR-750 Double/Ripple Wall Cup Making Machine is equipped with advanced features for efficient production. With a maximum speed of 75 pcs/min and stable operation at 55-60 pcs/min, it ensures reliable output. Featuring auto lubrication and a high-speed open CAM, gear-based mechanism, it’s user-friendly. Suitable for cups from 200 ML to 950 ML and paper thickness from 160 to 350 GSM.
| S no | Model | |||
|---|---|---|---|---|
| 1 | Automation | High Speed Open CAM, Gear based, Fully Automatic Machine | ||
| 2 | Lubrication | Auto Lubrication | ||
| 3 | Maximum Speed | 0-75 Pcs/Min | ||
| 4 | Stable Speed | 55-60Pcs/Min | ||
| 5 | Power source | 3 Phase 380V 50Hz | ||
| 6 | General power | 5.0 kw | ||
| 7 | Weight | 2200 Kg | ||
| 8 | Dimension | 2650x1300x1800 MM | ||
| 9 | Cup Size | 200 ML - 950ML | ||
| 10 | Maximum Cup Height | 130 MM | ||
| 11 | Paper Specification | 160-350 GSM |
The BX-700 Paper Bowl Machine ensures efficient, automated production. Operating at 50-55 pcs/min with a max speed of 70 pcs/min, it delivers consistent output. Equipped with a high-speed open CAM, gear-based mechanism, and auto lubrication, it’s reliable and user-friendly. Accommodating bowl sizes from 150 ML to 1000 ML, with a top diameter of 90-150 MM and height of 50-130 MM, it offers design versatility. Supporting paper specifications from 170 to 350 GSM, it caters to diverse production needs. Sturdy and intuitive, the BX-700 is the top choice for efficient and high-quality paper bowl manufacturing.
| S no | Model | |||
|---|---|---|---|---|
| 1 | Automation | Hign Speed Open CAM, Gear based, Fully Automatic Machine | ||
| 2 | Lubrication | Auto Lubrication | ||
| 3 | Maximum Speed | 50-70 Pcs/Min | ||
| 4 | Stable Speed | 50-55Pcs/Min | ||
| 5 | Power source | 3 Phase 380V 50Hz | ||
| 6 | General power | 8.5 kw | ||
| 7 | Weight | 3000 Kg | ||
| 8 | Dimension | 2400x1400x1800 MM | ||
| 9 | Bowl Size | 150 ML - 1000ML | ||
| 10 | Top Diameter | 90-150 MM | ||
| 11 | Bowl Height | 50-130 MM | ||
| 12 | Knurling Depth | 6-10 MM | ||
| 13 | Paper Specification | 170-350 GSM |
The P 1200 Paper Plate Making Machine features a heavy, sturdy frame for durability. It operates at a speed of 90-120 pcs/min, handling materials from 180-500 GSM. With a PLC control panel and hydraulic pressure of 8 tons, it ensures reliable and efficient operation. The double station work station and robust construction make it ideal for high-quality paper plate production.
| S no | Model | |||
|---|---|---|---|---|
| 1 | Frame | Heavy Sturdy Frame | ||
| 2 | Production Speed | 90-120 Pcs/Min | ||
| 3 | Suitable Material | 180-500 GSM | ||
| 4 | Black Paper Size | 7-14" (180-350MM) | ||
| 5 | Total Power | 12KW | ||
| 6 | Weight | 1600 Kg | ||
| 7 | Dimension | 2600x1170x2000 MM | ||
| 8 | Control | PLC Control Panel | ||
| 9 | Pressure | Hydraulic-8 ton | ||
| 10 | Power Source | 3 Phase-380V,50Hz | ||
| 11 | Work Station | Double Station |
(SG-75) Cup forming machine is a fully automatic chain cup forming equipment, which is supplied by our company independently through comprehensive technical improvement to improve the stability of the whole machine
The cutting-edge, fully automated SG-75 chain cup forming machine is known for its exceptional performance and stability. With a staggering 75 cups per minute output capability, this machine is ideal for businesses looking to significantly increase productivity and efficiency in their manufacturing processes.
Its simple maintenance and user interface provide smooth operations, allowing your organization to run successfully and efficiently. To meet the needs of continuous, high-speed manufacturing, the SG-75 is designed to be dependable and durable.
| S no | Model | |||
|---|---|---|---|---|
| 1 | Model | SG-75 | ||
| 2 | Rated Speed | 60-70pcs/min | ||
| 3 | Paper Cup Size | 40-300ml (mold exchangeable) | ||
| 4 | Raw Material | 140-180gsm one side PE film coated paper | ||
| 5 | Power source | 380V, 50Hz Three Phase | ||
| 6 | Total power | 3.5 kw | ||
| 7 | Total weight | GW/NW:1400/1300KG | ||
| 8 | Overall dimension (LxWxH) | 2200X1100X1900mm | ||
| 9 | Working Air Source | No Need Air Compressor |
Model: 90 Pcs/min
Sahil’s SG-90 is a new fully automatic open-cam based machine for making High Quality Paper Cups with an excellent speed of 90 cups/min. The Overall technology is improved to increase the stability of the complete machine.
| S no | Name of equipment | |||
|---|---|---|---|---|
| 1 | Model | SG-90 | ||
| 2 | Speed | 80-85pcs/min, ( 3000-5000 PCS/Hour) | ||
| 3 | Paper Cup Size | 40-330 ml (Mold exchangeable) | ||
| 4 | Raw Material | 140-200 gsm One Side PE film coated paper | ||
| 5 | Power Source | 380V, 50Hz Three Phase | ||
| 6 | Total Power | 3.5Kw | ||
| 7 | Total Weight | GW/NW:2000/1900KG | ||
| 8 | Dimensions (LxWxH) | 2100X1300X1900mm |
At Sahil Graphics, we are aware that making the correct equipment investments is essential to the success of your business. We provide a variety of paper cup manufacturing equipment to suit every need and budget as a result. You receive the best return on your investment since our machines are made to last. Sahil Graphics is the best option for manufacturers of all sizes or tiny start-ups.
Are you ready to put in more hours at work?
Contact Sahil Graphics right now to find out more about our paper cup making machine price and how it can help your business. Sahil Graphics promises to deliver exceptional customer support, dependable operations, and a commitment to excellence.
